Vacuum Air Leak Tester For Packaging Materials Bottle Cans Bag Leak Leakage Tester Sealed Package Vacuum Leak Tester

Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xRange | -90KPa | Standards | ASTM D3078 , ASTM E515, GB/T 15171 |
---|---|---|---|
Power | 110~220V | Test Space | 270mm*210mm |
Method | Negative Pressure Vacuum Method |
Vacuum Air Leak Tester For Packaging Materials Bottle Cans Bag Leak Leakage Tester Sealed Package Vacuum Leak Tester
Test Range | 0~-90 KPa |
Chamber | Acrylic cylinder shape |
Test Space | Φ270*H210mm (Inside Usable) |
Compressed Air | 0.7MPa (Prepared by user) |
Power | 110V, or 220V 50/60Hz |
The Vacuum Air Leak Tester is a cutting-edge testing instrument designed for detecting leaks in various types of packaging materials, including bottles, cans, bags, and other sealed packages. With its advanced capabilities, this tester ensures the integrity of your packaging by detecting gross leaks that may compromise product quality and safety. Utilizing the vacuum leak detection method based on ASTM D3078 bubble emission standards, the Vacuum Air Leak Tester is ideal for industries such as packaging, food, pharmaceuticals, and beverages.
This versatile Vacuum Air Leak Tester is engineered to test flexible packaging with headspace gas, providing an efficient and reliable solution for quality control in packaging lines. Whether you're testing bottles, bags, or any sealed package, this instrument guarantees that your products meet the highest standards for leak prevention.
Working Principle of the Vacuum Air Leak Tester
The Vacuum Air Leak Tester operates by creating a vacuum inside a sealed package. Once the vacuum is drawn, positive pressure is applied, forcing air to flow through any small leaks present. This method effectively identifies and locates leaks, ensuring that packaging remains airtight and capable of maintaining the desired product conditions. The technology behind this device ensures accuracy, reliability, and efficiency in detecting leaks, whether small or large.
By using the Vacuum Air Leak Tester, manufacturers can minimize risks related to product spoilage, contamination, and loss of quality, ensuring that packaging standards are met in compliance with industry regulations.
Key Features of the Vacuum Air Leak Tester
Advanced Vacuum Ejector System
The Vacuum Air Leak Tester employs a vacuum ejector system, which is superior to traditional vacuum pumps in terms of stability and efficiency in creating the necessary pressure for leak detection. This ensures consistent and reliable results throughout the testing process.Digital Vacuum Degree and Test Time Control
For ease of operation, the tester offers precise digital settings for both vacuum degree and test time. This allows users to configure the device according to specific requirements for various packaging types and leak testing conditions.Automatic Vacuum Maintenance and Air Back-Flushing
The Vacuum Air Leak Tester features an automatic vacuum maintenance system that maintains a consistent vacuum level during testing. Additionally, the air back-flushing function clears the system between tests, ensuring cleanliness and reliability.User-Friendly Design
With a focus on simplicity and convenience, the Vacuum Air Leak Tester is designed for easy operation and maintenance. The intuitive interface allows users to quickly get up to speed with minimal training.High-Quality PMMA Chamber
The Vacuum Air Leak Tester is equipped with a transparent, thick, and durable PMMA chamber that provides a clear view of the testing process. The chamber’s robust design ensures long-lasting performance under regular use.Customizable Chamber Sizes
The tester can be customized with different chamber sizes to suit your specific packaging requirements. This flexibility makes the Vacuum Air Leak Tester adaptable to a wide range of packaging materials and product types.
Technical Specifications of the Vacuum Air Leak Tester
- Vacuum Range: 0~-90KPa / 0~-13PSI
- Vacuum Chamber Size: Φ270 mm x 210 mm (H) (Standard)
- Gas Source: Compressed air
- Gas Pressure: 0.7MPa / 101.5PSI
These specifications highlight the Vacuum Air Leak Tester's capability to work with different packaging materials, providing a comprehensive leak detection solution for manufacturers across multiple industries.
Why Choose the Vacuum Air Leak Tester?
The Vacuum Air Leak Tester is indispensable for manufacturers looking to ensure airtight packaging and prevent product contamination. Whether for food, beverage, pharmaceutical, or other packaged goods, this tester provides the necessary assurance that packaging maintains the required vacuum seals. By integrating the latest leak detection technology, the Vacuum Air Leak Tester helps businesses maintain quality standards and reduce waste caused by leaks in packaging.
In addition to being highly efficient, the Vacuum Air Leak Tester is built with durability in mind, ensuring long-term performance and reliability. Its customizable features and user-friendly design make it an ideal choice for both small and large-scale manufacturers.
Applications of the Vacuum Air Leak Tester
- Packaging Industry: Ensures that flexible packaging such as bags, pouches, and wraps are sealed properly and free of leaks.
- Food and Beverage: Assures that product packaging remains sealed to preserve freshness and prevent contamination.
- Pharmaceuticals: Verifies that drug packaging maintains its integrity and prevents exposure to air or moisture.
- Medical Packaging: Ensures that sterile packaging remains intact and free of leaks to protect medical products.
- Consumer Goods and Other Industries: Ensures that products are protected during transit and storage, maintaining the integrity of the packaging.
