Automatic digital tensile tester with minor stroke CELL INSTRUMENTS brand Tension and elongation tester ASTM D882

Large Image : Automatic digital tensile tester with minor stroke CELL INSTRUMENTS brand Tension and elongation tester ASTM D882

Product Details:

Place of Origin:	China
Brand Name:	Cell Instruments
Model Number:	TST-01S

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Packaging Details:	export carton
Delivery Time:	7 days
Payment Terms:	TT LC
Supply Ability:	100 sets/m
Minimum Order Quantity:	1 set

Contact Now

Detailed Product Description

Product Name:	Nylon Material Tensile Testing Machine,Electronic Tensile Testing Machine	Accuracy:	±0.5%
Test Speed:	1-500mm/min (adjustable )	Screw:	High Precise Ball Screw

TST-01S Tensile Tester is a PLC controlled unit(industrial level stable) and HMI touch screen operated device, with precious ball lead screw. Multiple test items available including break, strength, elongation, heat seal strength, tearing, peeling etc. Other applications also available with extended program and accessories.

Automatic digital tensile tester with minor stroke CELL INSTRUMENTS brand Tension and elongation tester ASTM D882

TST-01S tensile tester features

1. 7 inch TFT touch screen operation
2. PLC control
3. Precision ball screw
4. Test speed adjustable.
5. Multiple fixtures available
6. Limiting device and automatic returning function
7. Multiple test items available.
8. Microprinter
9. Software(optional)

Bench Top Tensile Tester Technical Specifications

Test Range	0-500N (Standard, 50N,100N,200N are optional)
Speed	1-500 mm/min
Accuracy	0.5% F.S. 0.01mm
Effective stroke	350mm

Control: PLC and human machine interface

Data Output: Screen, Microprinter(optional), RS232(optional)

Dimension: 350mm*450mm*1250mm(LWH)

Automatic digital tensile tester with minor stroke CELL INSTRUMENTS brand Tension and elongation tester ASTM D882

Bench Top Tensile Tester Standards

ISO 37, ASTM D882, ASTM E4, ASTM D3330, ASTM F904,ASTM F88, ASTM D1938, JIS P8113

Automatic digital tensile tester with minor stroke CELL INSTRUMENTS brand Tension and elongation tester ASTM D882
