Vacuum Leak Tester Package Bag Leak Testing Leak Tester Machine

Place of Origin China
Brand Name Cell Instruments
Certification CE
Model Number LT-03
Minimum Order Quantity 1 SET
Price Get An Offer
Packaging Details Plywood Carton
Delivery Time 3~5 days
Payment Terms TT, LC
Supply Ability At Stock

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Standard ASTM D3078 Test Sample Sealed Pack, Container Etc
Vacuum Range 0~-90 KPa Test Space 270mm*210mm
Chamber PMMA Brand Cell Instruments
Power 110~220V
Leave a Message
Product Description

Pet Preform And Bottle Leak Tester is used to check the airproof property of packages, containers, bags, pipes.



CELL INSTRUMENTS LT-03 Vacuum air leak tester for package is widely used in food, beverage, pharmaceutical, daily chemical, electrical and electronic industries, etc.



Pet Preform And Bottle Leak Testercomplies with ASTM D3078 and GB/T 15171 standards.

Vacuum Leak Tester Package Bag Leak Testing Leak Tester Machine 0

Technical​ Features

1. Test process all automatic

2. HMI Touching screen operation and PLC controlled

3. Digital vacuum degree and test time input

4. Parameters and test data automatic saving

5. Automatic vacuum maintenance and air back-flushing

6. Strong cast vaccum chamber

7. Different chamber sizes available

8. No vacuum pump required

9. Easy operation and maintenance



Vacuum Leak Tester Package Bag Leak Testing Leak Tester Machine 1



Pet Preform And Bottle Leak Tester​ Technical Specification

Vacuum Level 0~-90KPa/0~-13PSI

Vacuum chamber size

Φ270 mm x 210 mm (H) (Customization available)

Gas source

Compressed air

Gas Pressure 0.7MPa/101.5PSI



Pet Preform And Bottle Leak Tester Standards

ASTM D3078 , GB/T 15171



Vacuum Leak Tester Package Bag Leak Testing Leak Tester Machine 2

Vacuum Leak Tester Package Bag Leak Testing Leak Tester Machine 3



Vacuum Leak Tester Package Bag Leak Testing Leak Tester Machine 4

Vacuum Leak Tester Package Bag Leak Testing Leak Tester Machine 5

Vacuum Leak Tester Package Bag Leak Testing Leak Tester Machine 6
