Tensile tester can be used to measure tensile, peeling, deformation, tearing, heat sealing, adhesive, puncture force, opening force and other performance of plastic films, composite materials, soft package materials, plastic flexible tube, adhesives, adhesive tape, label stickers, medical plasters, release paper, protection films, combined caps, aluminum foil, diaphragm, back sheets, non-woven fabrics, rubber, paper, etc.
Tensile Tester Features
1. 7 inch TFT touch screen operation
2. PLC control
3. Precision ball screw
4. Test speed adjustable.
5. Multiple testing items can be chosen
6. Multiple fixtures available
7. Data storage and analysis
8. Limiting device and automatic returning function
Tensile Tester Technical Specifications
Test Range: 0-500 (Standard, 50N,100N,200N are optional)
Speed: 1-500 mm/m (stepless speed changing)
Accuracy: 0.5% F.S.
Stroke: 800 mm
Tensile Tester Standards
ISO 37, ASTM D882, ASTM E4, ASTM D3330, ASTM F904,ASTM F88, ASTM D1938, JIS P8113
