Tensile Strength Tester Digital Tensile Tester Universal Testing Machine BOPP Film Tensile Tester Films Tensile Testing

Place of Origin China
Brand Name Cell Instruments
Certification CE
Model Number TST-01
Minimum Order Quantity 1 SET
Price Get An Offer
Packaging Details Plywood Carton
Delivery Time 3~5 days
Payment Terms TT, LC
Supply Ability At Stock

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Power Electronic,220V/50HZ Or 110V/60HZ Usage Tensile Testing Machine
Warranty 12 Months Accuracy ±0.5%
Test Speed 1-500mm/min (adjustable )
Highlight

tensile

,

strength

,

benchtop

Leave a Message
Product Description

Tensile Strength Tester Digital Tensile Tester Universal Testing Machine BOPP Film Tensile Tester Films Tensile Testing

Tensile Strength Tester Digital Tensile Tester Universal Testing Machine BOPP Film Tensile Tester Films Tensile Testing 0



Test Range 0-500N (or 50N, 100N, 200N, etc)
Stroke 800mm (customizable for other strokes)
Test Speed 1~500mm/min
Displacement Accuracy 0.01mm
Accuracy 0.5% Full Scale
Sample Width 27mm (optional width available)
Control PLC and HMI Screen
Data Output Microprinter (optional), RS232 (optional)



Overview: The BOPP Film Tensile Tester is an advanced digital testing instrument designed to evaluate the physical properties of BOPP films and various materials used in packaging and other applications. This versatile tensile strength tester measures a wide range of performance attributes, including tensile strength, peeling, deformation, tearing, heat sealing, adhesive properties, puncture force, and opening force. It is ideal for laboratories and industries involved in packaging, food, medicine, and beverages.

Key Applications: The BOPP Film Tensile Tester is essential for assessing the performance of:

  • Plastic films
  • Composite materials
  • Soft packaging materials
  • Plastic flexible tubes
  • Adhesives and adhesive tapes
  • Label stickers and medical plasters
  • Release paper and protective films
  • Combined caps and aluminum foils
  • Diaphragms and back sheets
  • Non-woven fabrics, rubber, and paper

Main Technical Features:

  1. Touch Screen Operation: User-friendly interface for easy navigation and operation.
  2. PLC Control Unit: Ensures precise control of test parameters and reliable performance.
  3. Precision Ball Screw and Stepper Motor: Provides high accuracy and repeatability in measurements.
  4. Adjustable Test Speed: Range from 1-500 mm/min to accommodate various testing needs.
  5. Multiple Test Items Available: Allows users to perform a comprehensive range of tests on different materials.
  6. Variety of Fixtures: Customized fixtures ensure compatibility with different specimen types.
  7. Limiting Device and Automatic Return: Enhances safety and efficiency during testing.
  8. Microprinter and Software (Optional): Provides instant printouts of test results and data analysis capabilities.

Technical Specifications:

  • Test Range: 0-500N (with options for 50N, 100N, 200N, and 1000N)
  • Speed: Adjustable between 1-500 mm/min
  • Accuracy: ±0.5% F.S.

Standards Compliance: The BOPP Film Tensile Tester meets various industry standards, including:

  • ISO 37
  • ASTM D882
  • ASTM E4
  • ASTM D3330
  • ASTM F904
  • ASTM F88
  • ASTM D1938
  • JIS P8113

Conclusion: For reliable and accurate testing of BOPP films and other materials, the BOPP Film Tensile Tester is an indispensable tool. Its robust features and compliance with international testing standards make it the ideal choice for laboratories and industries aiming for quality assurance in their products.

Tensile Strength Tester Digital Tensile Tester Universal Testing Machine BOPP Film Tensile Tester Films Tensile Testing 1
